ORACLE12CR2 RAC安裝部署（REDHAT7.6）三、Grid 執行ROOT.SH報錯

Grid 執行ROOT.SH

先節點一執行：

[root@fdcdb01 grid]# /u01/app/12.2.0/grid/root.sh Performing root user operation. The following environment variables are set as: ORACLE_OWNER= grid ORACLE_HOME= /u01/app/12.2.0/grid Enter the full pathname of the local bin directory: [/usr/local/bin]: Copying dbhome to /usr/local/bin ... Copying oraenv to /usr/local/bin ... Copying coraenv to /usr/local/bin ... Creating /etc/oratab file... Entries will be added to the /etc/oratab file as needed by Database Configuration Assistant when a Database is created Finished running generic part of root script. Now product-specific root actions will be performed. Relinking oracle with rac_on option Using configuration parameter file: /u01/app/12.2.0/grid/crs/install/crsconfig_params The log of current session can be found at: /u01/app/grid/crsdata/fdcdb01/crsconfig/rootcrs_fdcdb01_2021-04-02_06-09-31AM.log 2021/04/02 06:09:34 CLSRSC-594: Executing installation step 1 of 19: 'SetupTFA'. 2021/04/02 06:09:34 CLSRSC-4001: Installing Oracle Trace File Analyzer (TFA) Collector. 2021/04/02 06:09:59 CLSRSC-4002: Successfully installed Oracle Trace File Analyzer (TFA) Collector. 2021/04/02 06:09:59 CLSRSC-594: Executing installation step 2 of 19: 'ValidateEnv'. 2021/04/02 06:10:05 CLSRSC-363: User ignored prerequisites during installation 2021/04/02 06:10:05 CLSRSC-594: Executing installation step 3 of 19: 'CheckFirstNode'. 2021/04/02 06:10:08 CLSRSC-594: Executing installation step 4 of 19: 'GenSiteGUIDs'. 2021/04/02 06:10:09 CLSRSC-594: Executing installation step 5 of 19: 'SaveParamFile'. 2021/04/02 06:10:16 CLSRSC-594: Executing installation step 6 of 19: 'SetupOSD'. 2021/04/02 06:10:31 CLSRSC-594: Executing installation step 7 of 19: 'CheckCRSConfig'. 2021/04/02 06:10:31 CLSRSC-594: Executing installation step 8 of 19: 'SetupLocalGPNP'. 2021/04/02 06:10:47 CLSRSC-594: Executing installation step 9 of 19: 'ConfigOLR'. 2021/04/02 06:10:53 CLSRSC-594: Executing installation step 10 of 19: 'ConfigCHMOS'. 2021/04/02 06:10:53 CLSRSC-594: Executing installation step 11 of 19: 'CreateOHASD'. 2021/04/02 06:10:57 CLSRSC-594: Executing installation step 12 of 19: 'ConfigOHASD'. 2021/04/02 06:11:13 CLSRSC-330: Adding Clusterware entries to file 'oracle-ohasd.service' 2021/04/02 06:11:57 CLSRSC-594: Executing installation step 13 of 19: 'InstallAFD'. 2021/04/02 06:12:01 CLSRSC-594: Executing installation step 14 of 19: 'InstallACFS'. CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' has completed CRS-4133: Oracle High Availability Services has been stopped. CRS-4123: Oracle High Availability Services has been started. 2021/04/02 06:12:50 CLSRSC-400: A system reboot is required to continue installing. The command '/u01/app/12.2.0/grid/perl/bin/perl -I/u01/app/12.2.0/grid/perl/lib -I/u01/app/12.2.0/grid/crs/install /u01/app/12.2.0/grid/crs/install/rootcrs.pl ' execution failed

**ALERT: root.sh Fails With “CLSRSC-400” While Installing GI 12.2.0.1 on RHEL or OL with RedHat Compatible Kernel (RHCK) 7.3 (Doc ID 2284463.1)??**

根據mos文檔的方式，打補丁之后，依然報錯。

使用deinstall卸載GRID軟件，重新安裝。

Notes：這里是12201GRID的一個bug，嘗試使用applyPSU的方式在安裝GRID軟件之前打好PSU補丁：

##更換OPatch包 su - grid -c "/u01/app/12.2.0/grid/OPatch/opatch version" OPatch Version: 12.2.0.1.6 ##You must use the OPatch utility version 12.2.0.1.23 or later to apply this patch. mv /u01/app/12.2.0/grid/OPatch /u01/app/12.2.0/grid/OPatchbak su - grid -c "unzip /soft/p6880880_122010_Linux-x86-64.zip -d /u01/app/12.2.0/grid/" su - grid -c "/u01/app/12.2.0/grid/OPatch/opatch version" OPatch Version: 12.2.0.1.24 su - grid ./gridSetup.sh -applyPSU /soft/32226491

以上安裝步驟同上，省略、、、

打完補丁之后checks不再報以上錯誤，繼續執行root.sh。

先節點一執行root.sh：

[root@fdcdb01 ~]# /u01/app/12.2.0/grid/root.sh Performing root user operation. The following environment variables are set as: ORACLE_OWNER= grid ORACLE_HOME= /u01/app/12.2.0/grid Enter the full pathname of the local bin directory: [/usr/local/bin]: The contents of "dbhome" have not changed. No need to overwrite. The contents of "oraenv" have not changed. No need to overwrite. The contents of "coraenv" have not changed. No need to overwrite. Creating /etc/oratab file... Entries will be added to the /etc/oratab file as needed by Database Configuration Assistant when a database is created Finished running generic part of root script. Now product-specific root actions will be performed. Relinking oracle with rac_on option Using configuration parameter file: /u01/app/12.2.0/grid/crs/install/crsconfig_params The log of current session can be found at: /u01/app/grid/crsdata/fdcdb01/crsconfig/rootcrs_fdcdb01_2021-04-01_04-49-48PM.log 2021/04/01 16:49:50 CLSRSC-594: Executing installation step 1 of 19: 'SetupTFA'. 2021/04/01 16:49:50 CLSRSC-4001: Installing Oracle Trace File Analyzer (TFA) Collector. 2021/04/01 16:50:40 CLSRSC-4002: Successfully installed Oracle Trace File Analyzer (TFA) Collector. 2021/04/01 16:50:40 CLSRSC-594: Executing installation step 2 of 19: 'ValidateEnv'. 2021/04/01 16:50:48 CLSRSC-363: User ignored prerequisites during installation 2021/04/01 16:50:48 CLSRSC-594: Executing installation step 3 of 19: 'CheckFirstNode'. 2021/04/01 16:50:50 CLSRSC-594: Executing installation step 4 of 19: 'GenSiteGUIDs'. 2021/04/01 16:50:56 CLSRSC-594: Executing installation step 5 of 19: 'SaveParamFile'. 2021/04/01 16:51:11 CLSRSC-594: Executing installation step 6 of 19: 'SetupOSD'. 2021/04/01 16:51:24 CLSRSC-594: Executing installation step 7 of 19: 'CheckCRSConfig'. 2021/04/01 16:51:24 CLSRSC-594: Executing installation step 8 of 19: 'SetupLocalGPNP'. 2021/04/01 16:51:50 CLSRSC-594: Executing installation step 9 of 19: 'ConfigOLR'. 2021/04/01 16:52:10 CLSRSC-594: Executing installation step 10 of 19: 'ConfigCHMOS'. 2021/04/01 16:52:11 CLSRSC-594: Executing installation step 11 of 19: 'CreateOHASD'. 2021/04/01 16:52:25 CLSRSC-594: Executing installation step 12 of 19: 'ConfigOHASD'. 2021/04/01 16:52:40 CLSRSC-330: Adding Clusterware entries to file 'oracle-ohasd.service' 2021/04/01 16:53:19 CLSRSC-594: Executing installation step 13 of 19: 'InstallAFD'. 2021/04/01 16:53:33 CLSRSC-594: Executing installation step 14 of 19: 'InstallACFS'. CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' has completed CRS-4133: Oracle High Availability Services has been stopped. CRS-4123: Oracle High Availability Services has been started. 2021/04/01 16:54:20 CLSRSC-594: Executing installation step 15 of 19: 'InstallKA'. 2021/04/01 16:54:34 CLSRSC-594: Executing installation step 16 of 19: 'InitConfig'. CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' has completed CRS-4133: Oracle High Availability Services has been stopped. CRS-4123: Oracle High Availability Services has been started. CRS-2672: Attempting to start 'ora.evmd' on 'fdcdb01' CRS-2672: Attempting to start 'ora.mdnsd' on 'fdcdb01' CRS-2676: Start of 'ora.mdnsd' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.evmd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.gpnpd' on 'fdcdb01' CRS-2676: Start of 'ora.gpnpd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.cssdmonitor' on 'fdcdb01' CRS-2672: Attempting to start 'ora.gipcd' on 'fdcdb01' CRS-2676: Start of 'ora.cssdmonitor' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.gipcd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.cssd' on 'fdcdb01' CRS-2672: Attempting to start 'ora.diskmon' on 'fdcdb01' CRS-2676: Start of 'ora.diskmon' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.cssd' on 'fdcdb01' succeeded Disk groups created successfully. Check /u01/app/grid/cfgtoollogs/asmca/asmca-210401PM045515.log for details. 2021/04/01 16:55:49 CLSRSC-482: Running command: '/u01/app/12.2.0/grid/bin/ocrconfig -upgrade grid oinstall' CRS-2672: Attempting to start 'ora.crf' on 'fdcdb01' CRS-2672: Attempting to start 'ora.storage' on 'fdcdb01' CRS-2676: Start of 'ora.storage' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.crf' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.crsd' on 'fdcdb01' CRS-2676: Start of 'ora.crsd' on 'fdcdb01' succeeded CRS-4256: Updating the profile Successful addition of voting disk e19e9dd1dab24fc1bfa53d8fea38c5cd. Successfully replaced voting disk group with +OCR. CRS-4256: Updating the profile CRS-4266: Voting file(s) successfully replaced ## STATE File Universal Id File Name Disk group -- ----- ----------------- --------- --------- 1. ONLINE e19e9dd1dab24fc1bfa53d8fea38c5cd (/dev/asmdisks/asm_ocr) [OCR] Located 1 voting disk(s). CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' CRS-2673: Attempting to stop 'ora.crsd' on 'fdcdb01' CRS-2677: Stop of 'ora.crsd' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.storage' on 'fdcdb01' CRS-2673: Attempting to stop 'ora.crf' on 'fdcdb01' CRS-2673: Attempting to stop 'ora.drivers.acfs' on 'fdcdb01' CRS-2673: Attempting to stop 'ora.gpnpd' on 'fdcdb01' CRS-2673: Attempting to stop 'ora.mdnsd' on 'fdcdb01' CRS-2677: Stop of 'ora.drivers.acfs' on 'fdcdb01' succeeded CRS-2677: Stop of 'ora.crf' on 'fdcdb01' succeeded CRS-2677: Stop of 'ora.gpnpd' on 'fdcdb01' succeeded CRS-2677: Stop of 'ora.storage' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.asm' on 'fdcdb01' CRS-2677: Stop of 'ora.mdnsd' on 'fdcdb01' succeeded CRS-2677: Stop of 'ora.asm' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.cluster_interconnect.haip' on 'fdcdb01' CRS-2677: Stop of 'ora.cluster_interconnect.haip' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.ctssd' on 'fdcdb01' CRS-2673: Attempting to stop 'ora.evmd' on 'fdcdb01' CRS-2677: Stop of 'ora.evmd' on 'fdcdb01' succeeded CRS-2677: Stop of 'ora.ctssd' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.cssd' on 'fdcdb01' CRS-2677: Stop of 'ora.cssd' on 'fdcdb01' succeeded CRS-2673: Attempting to stop 'ora.gipcd' on 'fdcdb01' CRS-2677: Stop of 'ora.gipcd' on 'fdcdb01' succeeded CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'fdcdb01' has completed CRS-4133: Oracle High Availability Services has been stopped. 2021/04/01 16:57:24 CLSRSC-594: Executing installation step 17 of 19: 'StartCluster'. CRS-4123: Starting Oracle High Availability Services-managed resources CRS-2672: Attempting to start 'ora.evmd' on 'fdcdb01' CRS-2672: Attempting to start 'ora.mdnsd' on 'fdcdb01' CRS-2676: Start of 'ora.mdnsd' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.evmd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.gpnpd' on 'fdcdb01' CRS-2676: Start of 'ora.gpnpd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.gipcd' on 'fdcdb01' CRS-2676: Start of 'ora.gipcd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.cssdmonitor' on 'fdcdb01' CRS-2676: Start of 'ora.cssdmonitor' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.cssd' on 'fdcdb01' CRS-2672: Attempting to start 'ora.diskmon' on 'fdcdb01' CRS-2676: Start of 'ora.diskmon' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.cssd' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.cluster_interconnect.haip' on 'fdcdb01' CRS-2672: Attempting to start 'ora.ctssd' on 'fdcdb01' CRS-2676: Start of 'ora.ctssd' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.cluster_interconnect.haip' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.asm' on 'fdcdb01' CRS-2676: Start of 'ora.asm' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.storage' on 'fdcdb01' CRS-2676: Start of 'ora.storage' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.crf' on 'fdcdb01' CRS-2676: Start of 'ora.crf' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.crsd' on 'fdcdb01' CRS-2676: Start of 'ora.crsd' on 'fdcdb01' succeeded CRS-6023: Starting Oracle Cluster Ready Services-managed resources CRS-6017: Processing resource auto-start for servers: fdcdb01 CRS-6016: Resource auto-start has completed for server fdcdb01 CRS-6024: Completed start of Oracle Cluster Ready Services-managed resources CRS-4123: Oracle High Availability Services has been started. 2021/04/01 16:58:53 CLSRSC-343: Successfully started Oracle Clusterware stack 2021/04/01 16:58:53 CLSRSC-594: Executing installation step 18 of 19: 'ConfigNode'. CRS-2672: Attempting to start 'ora.ASMNET1LSNR_ASM.lsnr' on 'fdcdb01' CRS-2672: Attempting to start 'ora.ASMNET2LSNR_ASM.lsnr' on 'fdcdb01' CRS-2676: Start of 'ora.ASMNET2LSNR_ASM.lsnr' on 'fdcdb01' succeeded CRS-2676: Start of 'ora.ASMNET1LSNR_ASM.lsnr' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.asm' on 'fdcdb01' CRS-2676: Start of 'ora.asm' on 'fdcdb01' succeeded CRS-2672: Attempting to start 'ora.OCR.dg' on 'fdcdb01' CRS-2676: Start of 'ora.OCR.dg' on 'fdcdb01' succeeded 2021/04/01 16:59:59 CLSRSC-594: Executing installation step 19 of 19: 'PostConfig'. 2021/04/01 17:05:03 CLSRSC-614: failed to get the list of configured diskgroups Died at /u01/app/12.2.0/grid/crs/install/oraasm.pm line 2069. The command '/u01/app/12.2.0/grid/perl/bin/perl -I/u01/app/12.2.0/grid/perl/lib -I/u01/app/12.2.0/grid/crs/install /u01/app/12.2.0/grid/crs/install/rootcrs.pl ' execution failed

節點一執行root.sh報錯，并且執行asmcmd報錯如下：

[grid@fdcdb01 ~]$ asmcmd -p kgfnGetConnDetails requires 4 parameters at /u01/app/12.2.0/grid/lib/asmcmdbase.pm line 5704.

可參考MOS文檔：

**Install.sh Hung And root.sh Is Failing At asmcmd lsdg --suppressheader While Installing A Zone With Clusterware (Doc ID 2414241.1)?? ?**

**ASMCMD Failing With "KGFNGETCONNDETAILS Requires 4 Parameters at /lib/asmcmdbase.pm (Doc ID 2748316.1)?? ?**
